Handheld fiber laser welding machine

Product features:
Handheld fiber laser welding machineConnected to a 5-meter-long imported optical fiber, the laser head can be used for long-distance welding of large and non moving products. Due to the transmission of optical fibers, the laser energy is more concentrated and can penetrate stainless steel metal of more than 2mm. It can be used for spot welding, butt welding, stacking welding, and sealing welding of stainless steel products, completing complex welding of flat lines, arcs, and any trajectory. High welding efficiency, good results, simple and convenient operation, and the laser head can also be fixed to achieve automated welding of products.
All key components of the machine are imported from abroad. The software operation interface adopts a large screen LCD display with a fully Chinese interface that is simple and clear. It has high-definition CCD observation videos to synchronize welding work, making it easy for operators to learn and use. Multiple pre storage operation modes, permanent memory function, suitable for various materials. Adopting 5-meter imported optical fiber and handheld head, it is suitable for various processes and can be flexibly applied.

Product advantages:
1. Fiber optic transmission has better beam quality, more uniform solder joints, and better penetration depth.
2. Handheld is more convenient and efficient, with less restrictions on space and workpiece size.
3. All optical fibers are made of imported materials, which have good durability.
4. For irregular shapes of larger objects.
5. The whole machine adopts dual fiber soft optical path with good extensibility and strong mobility.
6. It is particularly suitable for ultra-thin welding that cannot be welded by argon arc welding and has good welding effect.

Technical Parameter
Maximum laser power:	400W
Laser wavelength:	1064nm
Maximum laser energy per single pulse:	100J
Single pulse width:	0.5ms-20ms
Continuous pulse width per unit time (1 second):	100ms/s
Welding depth:	Maximum 3mm/stainless steel
Pulse frequency:	1-100HZ
Whole machine power:	12KW
Power input:	Three phase 380V/50Hz
Cooling method:	water-cooling
Host size:	610W*1200D*1000H
Fiber optic model:	GI/SI 600 fiber optic

Application areas:
Widely used for welding in various fields such as cabinets, kitchens and bathrooms, stairs, elevators, shelves, stainless steel doors and windows, guardrails, distribution boxes, stainless steel homes, etc

Application case:
