German Fischer thickness gauge probe FTD3.3

Product description

German Fischer thickness gauge probe FTD3.3

The core of any electromagnetic measurement system will be the probe, and its signal quality ultimately determines the overall measurement quality of the measurement scheme. After years of research and innovation, FISCHER now has over 100 probes that can achieve high measurement repeatability and accuracy in various measurement tasks. High precision eddy current probe Eddy Currrent Probe. FISCHER now has over 100 probes that can achieve high measurement repeatability and accuracy in various measurement tasks.FTD3.3Measure non-conductive coatings on non ferromagnetic metal substrates (NC/NF). Has good curvature compensation, especially suitable for measuring on curved surfaces such as car bodies, blinds, etc. Not applicable: In contact with acidic liquids, measure the concave curvature diameter of small thin coatings.

(NF) applied to non-magnetic metal substrates：
Aluminum, copper or brass coatings, varnishes or plastic coatings (NC/NF)
Anodized coating on aluminum

Measurement of Anodized Coatings Using Curvature Compensation Probe FTD3.3

illustration
Probe model	FTD3.3
Order Number	604-189(If there are any changes, no notice will be given)
Probe design	Axial single pointed probe with spring type measuring system
measurement method	Eddy current method
Measurement application	Iso/NF
measurement range	0 - 800Mm
accuracy	on f at specimen: 0 - 50Mm: 0.5Mm; 50 - 800Mm: 1 % on 8 mm convex: 0 - 50Mm: 2.5Mm; 50 - 800Mm: 5 %
repeatability accuracy	on f at specimen *: 0 - 100Mm: 0.5Mm 100 - 800Mm: 0.5 %
Diameter/Width	16 mm
length	100mm
Compatible Models	FMP10/20/30/40/100,MMS® PC & F-Modul PERMASCOPE®
size
