❶ Compressor: Imported variable frequency compressor, energy-saving>50%;

❷ Evaporator: Coating process, doubling anti-corrosion ability;

❸ Humidifier: PTC heating element, automatic protection function;

❹ Controller: 7-inch program touch screen;Third level permissions, which can allocate more levels; Audit tracking, storage operation records; Variable frequency characteristics, display variable frequency output; Prompt function, regularly maintain prompts;

❺ Humidity sensor: high-precision capacitive type;

❻ Waterway system: automatic water circulation with water level scale

❼ Alarm system: on-site sound and light alarm, remote information alarm;

❽ Structural material: Internal stainless steel 304, polyurethane foam insulation;

❾ Double layered door: The inner door is made of tempered glass, with door heating and anti condensation water;

❿ Security protection: Five fold protection, including independent over temperature protection;

Technical Specifications

❶ Temperature range: 10~65 ℃ ℃; Temperature fluctuation: ± 0.5 ℃; Temperature deviation:+1.0 ℃;

❷ Humidity range: 15~95% RH; humidity fluctuation: ± 2.0% RH; humidity deviation: ± 3.0% RH；

software configuration

❶ Data storage: Comes with a built-in storage hard drive, USB export, over 5 years old;

❷ Data printing: Needle micro printer, long-term storage;

❸ Data software: Multiple devices are connected locally, with software registration number 12559111;

❹ Data Network Version: Server version functionality, compliant with FDA 21CFR Part 11;

technical advantage

❶ Performance: Excellent uniformity enables the device to meet the requirements of ICH stability testing even at full load after years of use;

❷ Reliability: In addition to better volatility and uniformity, it has been tested in practical applications for over 17 years;

❸ Intelligence: In addition to more stable control, it also adds more maintenance reminders;

❹Benefit: By utilizing advanced variable frequency refrigeration technology, energy consumption has been reduced by over 50% compared to the previous generation;

❺Safety: Five fold protection, including critical leakage protection;

Public requirements

❶ Power supply: 220V 50Hz/60Hz;

❷ Water source: purified water, with a resistivity of ≥ 0.5 M Ω· cm;

❸ Environment: 5-35 ℃;

❹ Standard: Compliant with ICHQ1, CP2025, and national standards;

❺ Network: Connected through a network port.
