Shanghai Yidian IoT WRS-2C Melting Point Meter

NegotiableUpdate on 03/03

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Shanghai Yidian Physical Optics WRS-2C Melting Point Analyzer Company currently has more than 100 professional physical optical instrument products in 8 series, including polarimeter, melting point analyzer, refractometer, haze analyzer, colorimeter, laser particle size analyzer, turbidity analyzer, stress analyzer, etc.

Product Details

Shanghai Yidian IoT WRS-2C Melting Point Meter

Adopting photoelectric automatic detection and color LCD touch screen display.

The testing process automatically records the initial and final melting results, and can also display the initial and final melting curves of the sample.

The temperature control system uses precision platinum resistors as temperature detection elements, and applies PID regulation and PWM temperature control technology to improve the accuracy and reliability of melting point measurement.

The instrument has the function of automatically saving working parameters and storing measurement results. It can also be connected to a PC through a USB interface or RS232 interface, and can be connected to a printer.

The instrument uses capillary tubes specified in the pharmacopoeia as sample tubes.

Shanghai Yidian IoT WRS-2C Melting Point Meter

PRODUCT MODEL	WRS-2C
measuring range	Room temperature -360 ℃
measuring method	automatic
Minimum indication	0.1℃
heating rate	0.1Can be continuously selected between ℃/min and 20 ℃/min
Indication error	≤200℃ ±0.4℃ ＞200℃ ±0.7℃
Repeatability of indication values	Heating rate 1 ℃/min, 0.3 ℃
Linear heating rate error	±10％
Pre stored measurement mode	8species
processing capacity	3root
Capillary size	Outer diameter of 1.4mm, inner diameter of 1.0mm, length of 90mm
Sample height	3mm
Storage	1000group
Printer Model	RD-TH32-SC(Standard)
Display mode	7Inch color LCD touch screen
Calibration method	Multi point calibration
communication interface	RS232/USB
power supply	220V±22V，50 Hz
Instrument dimensions	360mm×290mm×170mm
Net weight of the instrument	9kg
