SZMN7045TR-BL3 Stereoscopic Microscope

eyepiece

10X/22mmAdjustable visual acuity

Optical observation head

Stereoscopic three eyed head, tilted at 45 °, continuously increasing magnification from 0.7-4.5X,

0.5XCamera interface, working distance 100mm.

Pupil adjustment range 54-60mm, visually adjustable 7X-45X continuously.

(Configure 10X eyepiece, objective 0.7X-4.5X)

Focusing bracket

SZMN-A1Focusing bracket, mirror aperture: Φ76mm， Column aperture: Φ32mm， Center distance: 150mm.

base

BL3Column style large fan-shaped upper and lower LED light source base

Column height 280mm, diameter Φ 32mm, large fan-shaped base 303 × 290 × 47mm
