QC12K hydraulic fully CNC swing shearing machine

Performance characteristics:
The host is equipped with QC12Y hydraulic swing shearing machine,Numerical Control SystemOptional imported and domestically advanced CNC systems from the Netherlands, Italy, Canada, and other countries. The frame and knife holder adopt an integral welding structure, which eliminates stress through vibration and maintains good accuracy.
Adopting advanced integrated hydraulic system with good reliability.
Adopting three-point support rolling guide rails to eliminate support gaps and improve shear quality.
The blade clearance handwheel adjustment is fast, accurate, and convenient.
Rectangular blade, all four edges can be used, with a long service life.
The cutting angle can be adjusted to reduce the distortion and deformation of the sheet metal.
The upper knife holder adopts an internal structure, which facilitates material dropping and improves the accuracy of the parts.
It has segmented cutting function.
Material blocking after maneuvering, digital display.
Technical parameters:

Specification \ \ Name	Scissorable board thickness	Scissorable board width	shear angle	Stroke times	Rear material range	Motor Power
	mm	mm	°	min	mm	kw
QC12K-4×2500	4	2500	1°30｀	18	20-600	4.0
QC12K-4×3200	4	3200	1°30｀	18	20-600	5.5
QC12K-4×4000	4	4000	1°30｀	12	20-600	5.5
QC12K-4×5000	4	5000	1°30｀	10	20-600	5.5
QC12K-4×6000	4	6000	1°30｀	7	20-800	7.5
QC12K-6×2500	6	2500	1°30｀	18	20-600	7.5
QC12K-6×3200	6	3200	1°30｀	14	20-600	7.5
QC12K-6×4000	6	4000	1°30｀	12	20-600	7.5
QC12K-6×5000	6	5000	1°30｀	10	20-600	7.5
QC12K-6×6000	6	6000	1°30｀	7	20-800	7.5
QC12K-8×2500	8	2500	1°30｀	14	20-600	7.5
QC12K-8×3200	8	3200	1°30｀	10	20-600	7.5
QC12K-8×4000	8	4000	1°30｀	8	20-600	11
QC12K-8×5000	8	5000	1°30｀	7	20-800	15
QC12K-8×6000	8	6000	1°30｀	6	20-800	15
QC12K-8×8000	8	8000	1°30｀	5	20-800	15
QC12K-10×2000	10	2000	1°30｀	12	20-600	11
QC12K-10×2500	10	2500	1°30｀	10	20-600	11
QC12K-10×3200	10	3200	1°30｀	10	20-600	11
QC12K-10×4000	10	4000	1°30｀	8	20-600	15
QC12K-12×2000	12	2000	2°	12	20-600	15
QC12K-12×2500	12	2500	2°	10	20-600	15
QC12K-12×3200	12	3200	2°	9	20-600	15
QC12K-12×4000	12	4000	2°	8	20-800	18.5
QC12K-12×5000	12	5000	2°	7	20-800	22
QC12K-12×6000	12	6000	2°	6	20-800	22
QC12K-12×8000	12	8000	2°	5	20-800	22
QC12K-16×2500	16	2500	2°	8	20-600	18.5
QC12K-16×3200	16	3200	2°	7	20-600	18.5
QC12K-16×4000	16	4000	2°	5	20-800	18.5
QC12K-20×2000	20	2000	2°30｀	8	20-600	22
QC12K-20×2500	20	2500	2°30｀	6	20-800	22
QC12K-20×3200	20	3200	2°30｀	6	20-800	30
QC12K-20×4000	20	4000	2°30｀	6	20-800	30
QC12K-25×2000	25	2000	3°	6	20-800	30
QC12K-25×2500	25	2500	3°	6	20-800	30
QC12K-25×3200	25	3200	3°	6	20-800	37
QC12K-30×2500	30	2500	3°30｀	6	20-800	37
QC12K-30×3200	30	3200	3°30｀	5	30-800	45
QC12K-40×2500	40	2500	3°30｀	5	30-800	55
QC12K-40×3200	40	3200	3°30｀	5	30-800	55
