Photomultiplier tube PMT bare tube wide spectrum high gain

NegotiableUpdate on 10/08

Model: TS-PMT-SD9

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

PMT bare tube with wide spectrum and high gain is a side window type photomultiplier tube designed specifically for low light precision detection. Using quartz glass windows and multi alkali photocathodes, the spectral response covers 165-900 nm (deep ultraviolet to near-infrared), and a 9-stage ring doubling structure achieves high gain of 10 ⁶ -10 ⁷ and nanosecond fast response. It is widely used in environmental monitoring, semiconductor detection, fluorescence analysis, chemiluminescence detection, and photon counting, and supports customized sensitivity, gain, and structure according to drawings.

Product Details

TAOMSUN

PMT Bare Tube Series · Precision Photoelectric Components

🤝 Overseas Tech Partner:METICULAB™

Photomultiplier Tube PMT Bare Tube – Wide Spectrum 165–900 nm, High Gain 1×10 ⁷, Customizable

Brand:TAOMSUN ｜Overseas Tech Support:METICULAB (Korea) ｜Model:TS-PMT-SD9 · Side-on · Quartz Window · Multi-Alkali Cathode

TAOMSUN PMT bare tube (TS-PMT-SD9)is a side-on photomultiplier tube designed for weak-light precision detection. Featuring a quartz glass window and multi-alkali photocathode, it covers a spectral response range of 165–900 nm (deep UV to near-infrared). With a 9-stage circular dynode structure, it achieves high gain of 10 ⁶–10⁷ and nanosecond-level fast response. Sensitivity grades, gain, and structural dimensions can be customized per drawings.

🔍 Key Features:wide spectral response 165–900 nm (deep-UV extension); high gain up to 1×10 ⁷ (single-photon level); fast response – rise time 2.2 ns, TTS 1.2 ns; low dark current 3–50 nA; quartz window (short-wave limit 165 nm); multi-alkali cathode (UV-VIS-NIR); 9-stage circular dynode; full customization per drawings.

📋 Technical Specifications

Model	TS-PMT-SD9
Type	Side-on / 9-stage circular dynode
Window Material	Quartz glass
Photocathode	Multi-alkali, 8×24 mm²
Spectral Range	165–900 nm
Supply Voltage	Typical 1250 V
Cathode Sensitivity	140 to 250 μA/lm
Anode Sensitivity	1400–2500 A/lm
Gain	1×10⁷ / 8×10⁶ / 3.3×10⁶
Dark Current	3–50 nA (30 min)
Rise Time	2.2 ns
TTS	1.2 ns
Operating Temperature	-30 ~ +50 ℃
Storage Temperature	-50 ~ +50 ℃
Voltage Divider	Equal-divider recommended; resistors 200 kΩ–1 MΩ (330 kΩ suggested); last 3 stages bypassed with 10 nF

*Typical values; custom configurations may vary slightly – subject to specification sheet confirmation.

⭐ Core Advantages

✅Wide Spectral Response– 165–900 nm, deep-UV extension

✅High Gain– Up to 1×10 ⁷, single-photon-level detection

✅Fast Response– Rise time 2.2 ns, TTS 1.2 ns

✅Low Dark Current– 3–50 nA, high SNR in weak light

✅Quartz Window– Excellent deep-UV transmittance

✅Multi-Alkali Cathode– UV-VIS-NIR broadband response

✅Ring Dynode Structure– Compact 9-stage, stable gain

✅Full Customization– Sensitivity, gain, structure per drawings

🎯 Main Application Fields

Environmental Monitoring Semiconductor Inspection Fluorescence Analysis Chemiluminescence Detection Spectral Analysis Photon Counting

🏆 Why Choose Us

1) Quick response within 24 hours on working days.

2) Specification verification and selection guidance per application.

3) Sensitivity grade, gain and dimensions customized per drawings (2D PDF/CAD with GD&T, 3D STEP/IGES).

4) Voltage-divider circuit recommendations included to simplify integration.

5) Manufactured by ISO 9001-certified partner factories; parameters verified against specification sheet.

💬 Send your application description or drawings for selection guidance and quotation.

❓ Frequently Asked Questions (FAQ)

Q: What is the spectral response range?
A: 165–900 nm (deep UV to NIR). Some grades extend to 870 nm.

Q: Does it require external high voltage?
A: Yes, typical 1250 V. Voltage-divider circuit recommendations are available.

Q: How do I choose the gain grade?
A: High-sensitivity fluorescence / photon counting 1×10 ⁷; general weak-light detection 8×10 ⁶; strong-light wide-dynamic scenes 3.3×10 ⁶.

Q: Can you customize?
A: Yes. Sensitivity grade, gain, and structural dimensions are customized per drawings.

Q: What drawing formats do you accept?
A: 2D drawings (PDF/CAD with GD&T) and 3D models (STEP/IGES).

Q: How are samples handled?
A: Custom samples are produced on request. A sample fee applies to cover materials and tooling; express shipping is arranged at buyer's cost.

Q: What is the lead time?
A: Approximately 30 days (factory lead time, excluding international shipping).

Q: What are your payment terms?
A: Payment is 100% T/T in advance.
