PPCS series environmentally friendly dust collector

PPCSType Series Environmental Protection Dust Removal Series

PPCSThe Type Series Environmental Dust Collector is a series of high-efficiency bag filters developed by our company through technical cooperation with relevant universities, based on the introduction of advanced foreign technology. It absorbs the advantages of various types of dust collectors such as chamber blowback and pulse jet cleaning, overcomes the disadvantages of insufficient kinetic energy intensity during chamber blowback and the simultaneous formation of "re adsorption" during pulse jet cleaning and filtration, and adopts a high-energy offline dust cleaning method. It has the characteristics of high dust cleaning intensity, long filter bag service life, high dust collection efficiency, and high filtration wind speed, which improves the performance of the dust collector and expands its range of use.

Main performance characteristics

1High dust collection efficiency adopts advanced chamber offline dust cleaning method to prevent the "re adsorption" phenomenon of dust after cleaning, ensuring the best dust cleaning intensity and effect. The dust collection efficiency is ≥99.99%The emission concentration fully meets the requirements of national environmental protection emission standards (emission concentration: thermal equipment<100mg/Nm³,Ventilation equipment<50mg/Nm³）.

2The scientific pre dust collection box structure and pulse cleaning method are used to handle high dust concentrations, allowing the machine to handle concentrations up to1300g/Nm³The dusty gas can be used as a vertical millSePaFinished product recycling equipment such as powder sorting machines.

3The whole machine adopts a high degree of self-controlPLCAutomatic control, and parameters can be adjusted according to process changes.

4The low maintenance cost is due to the advanced, reliable, and high-quality selection of key components in the structural design, which improves the reliability of the equipment and ensures the long-term stable operation of the dust collector. The maintenance cost is only the same as that of a general dust collector70%左右。

5The long average lifespan of filter bags is greatly improved by the pulse cleaning method and high-quality filter bags and accessories.

6The whole machine can be divided into compartments for bag replacement and maintenance, and the operating rate of the main unit reaches100%.

7Widely used in the building materials industry, such as cement mill, crushing, packaging, warehouse roof, batching, etcIn addition to systems such as grate coolers, they can also be used for environmental remediation in industries such as metallurgy, chemical engineering, and machinery.
