PEC-6000E Power Quality Analyzer (Harmonic Analyzer)
NegotiableUpdate on 03/31
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
PEC-6000E Power Quality Analyzer (Harmonic Analyzer)
Product Details
With the large-scale application of power electronics, the number of large equipment has doubled, and the frequent use of decentralized power sources has made the power system more complex, leading to frequent power failures. Quickly and accurately detecting faults and solving problems has become an urgent need for power companies.
PECThe power quality analyzer can help enterprises analyze power quality, prevent power interference and other emergencies related to power quality in advance, reduce management costs, and improve efficiency. At present, PEC power quality analyzer has become a reliable assistant for maintenance personnel of power supply bureaus, power management enterprises, and industrial users.
|
mechanical |
|
|
size |
263×168×65 mm |
|
weight |
2kg |
|
power supply |
|
|
mains electricity |
110V～240V |
|
Adapter output |
15V， 3A |
|
battery |
Rechargeable nickel hydrogen battery, 4500mAh |
|
Battery operating time |
6h |
|
Battery charging time |
5h (At an ambient temperature of 25 ℃ |
|
Power saving function |
LCD backlight brightness adjustable, standby time adjustable |
|
display |
|
|
size |
112.8×84.6mm |
|
color |
26QVGA |
|
resolution |
640×480 |
|
brightness |
The maximum brightness is 350 cd/m2 (Typ.), and users can adjust the actual brightness according to their needs. |
|
contrast |
500:1（Typ） |
|
viewing angle |
70/70/50/70 (Typ.)(CR≥ 10) (Left/Right/Up/Down) |
|
storage |
|
|
type |
TFCard (built-in) |
|
capacity |
8GB |
|
environment |
|
|
working environment |
0℃~+45 ℃, humidity below 90rh% |
|
storage environment |
-20℃~+50 ℃, humidity below 95rh% (non condensing) |
|
standard |
|
|
measurement method |
IEC61000-4-30 |
|
measured performance |
IEC61000-4-30 Alevel |
|
flickering |
IEC61000-4-15 |
|
harmonic |
IEC61000-4-7 |
|
crosstalk |
|
|
Between voltage input terminals |
-60dB at nominal frequency |
|
storage environment |
-95dB at nominal frequency |
|
common-mode rejection |
|
|
CMRR |
CMRR >60dB |
|
safety |
|
|
meet the standard |
GB 4793.1-2007/IEC 61010-1:2001The Electrical Equipment for Measurement, Control, and Laboratory Use Safety Requirements "Part 1: General Requirements. Safety level: CAT III 1000 V/CAT IV 600 V. |
|
Maximum voltage at banana input terminal |
1000V CAT III；600V CAT IV |
|
BNCMaximum input voltage |
10Vpeak |
