Ozone aging testing machine

NegotiableUpdate on 01/10

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The ozone aging test chamber provides a controlled and adjustable sealed environment for ozone concentration, temperature, or humidity. After standing or undergoing static or dynamic stretching for a period of time, the degree of cracking or other physical property changes in the test piece are checked to evaluate the ozone resistance of rubber and other products.

Product Details

The specifications of the ozone aging chamber/aging testing machine meet the standards:

ASTM-D1149、ASTM-D1171、ASTM D 380-94、ASTM D-3041、ISO 1431-1、ISO 1431-2、GB/T 7762-2014、GB/T 7127.1、ISO 1431-4:2004、GB/T 2951.21-2008、IEC 60811-2-1:2001、GB/T 13642-2015、HG/T 2716-2008、HG/T 2869、DIN 53509-1、JIS K 6259:2004、JIS D2061、GB/T 7127.1、GB/T11039.3-2005Wait.

Ozone aging chamber/aging testing machine specifications

The ozone generation method adopts a high-voltage ceramic corona discharge generator;

2. Use an imported ultraviolet ozone analyzer from the United States, with an ozone concentration deviation of no more than ± 2%;

3. Use ultraviolet absorption method (Beer Lambert law) to detect ozone concentration and continuously monitor it in real-time;

4 adjustable multi-stage PID ozone testing, temperature, and humidity closed-loop control;

5 ozone stretching fixtures, both fixture speed and elongation can be controlled. A single set of fixtures with a self rotating motion mechanism, and the motion trajectory meets the requirements of Figure 2 of ISO 1431-1:2004.
