Liaoning Modern 2BLM-3 No tillage Sowing Machine

NegotiableUpdate on 07/06
Model
Nature of the Manufacturer
Producers
Product Category
Place of Origin

Overview

[Video] 2015 China International Agricultural Machinery Exhibition - Liaoning Modern Agricultural Machinery Equipment Co., Ltd. Liaoning Modern 2BLM-3 No tillage Sowing Machine Product Introduction: The structural design is reasonable, and the layout and installation of components such as land preparation, fertilization, sowing, soil covering, and compaction are completed

Product Details

  • 2015中国国际农业机械展览会--辽宁现代农机装备有限公司

    [Video] 2015 China International Agricultural Machinery Exhibition - Liaoning Modern Agricultural Machinery Equipment Co., Ltd

Product Introduction of Liaoning Modern 2BLM-3 No tillage Sowing Machine

Reasonable structural design, complete the layout and installation of components such as land preparation, fertilization, sowing, soil covering, and compaction.

The front is equipped with pressure rollers and inserting trays to create favorable conditions for sowing.

Operation Characteristics of Liaoning Modern 2BLM-3 No tillage Seeder

It is a protective equipment advocated by the country.

One homework can complete functions such as land preparation, fertilization, sowing, soil covering, and compaction.

No tillage can achieve the coverage of roots and straw on the ground, reduce mechanical operations, inhibit water evaporation, increase organic matter content, prevent desertification, and improve the ecological environment.

Each individual seeder is equipped with an anti travel mechanism to ensure consistent sowing depth and enable single seed sowing.

Technical parameters of Liaoning Modern 2BLM-3 no till seeder

PRODUCT MODEL 2BLM-3
technical specifications
Dimensions: Length (mm) x Width (mm) x Height (mm) 2200×2400×1450
Whole machine weight (kg) 945
Line spacing range (mm) 550-700
Seed planter type Finger clip type
Type of fertilizer applicator External groove wheel
Type of fertilizer ditch opener Chisel shaped shovel
Type of seeding and trenching device Sliding knife type
Transportation gap (cm) 400
Supporting power (horsepower) 40-50
Working speed (km/h) 4.5-5.5
Production efficiency (mu/h) 6-8.5
