LWH-600 High speed Horizontal Roll Labeling Machine

• DESCRIPTION

Working video of high-speed horizontal rolling round bottle labeling machine

LWH600 high-speed servo horizontal rolling labeling machine

This model is mainly used for labeling various small circular containers, small circular hardware and plastic products. There are usually oral liquid horizontal roll labeling machines, medicine bottle horizontal roll labeling machines, metal cylinder horizontal roll labeling machines, pen rod horizontal roll labeling machines, and eyebrow pencil horizontal roll labeling machines ... wait.

Product features:
Suitable for cylindrical objects such as glass bottles, plastic bottles, batteries, etc. Cone shaped objects can be customized.
According to product requirements, printers or inkjet printers can be installed.
■ Can be operated independently or connected to a conveyor line

Technical parameters:
Machine Size 2000 (L) × 1250 (W) × 1750 (H) mm
Labeling speed (Output Speeed) 60-500pcs/min
■ High Label Object (mm) 25-95 mm
Is it suitable for the bottle diameter of 12-30mm
Label Height: 20-90mm
Label Length 25-80mm
■ Paste the sign precision ± 0.5mm
■ Roll inside diameter 76mm
Roll Outside Diameter 420mm
■ Power Supply: 220V 2kw 50/60HZ
Printing machine air source: 5Kg/c ㎡
