High intensity aviation obstruction light
NegotiableUpdate on 10/30
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Product Overview: High Intensity Aviation Obstacle Light G-165 (High Intensity) Intelligent Aviation Obstacle Light. Its advantage is that the light source uses four high-power, low-energy pulse strobe xenon cold state light source tubes
Product Details
Product Overview
High intensity aviation obstruction light
G—165The type (high-intensity) intelligent aviation obstacle light has the advantage of using four high-power, low-energy pulse strobe xenon cold state light source tubes as the light source.
The main control part of the lamp is produced usingCPUThe single-chip computer chip automatically controls the internal laser specific energy storage component, providing DC high voltage and ignition voltage of over 10000 volts, to supply four pulse strobe xenon cold state light source lamps, which emit strong instantaneous flashes every few seconds. Install four pulse strobe xenon cold state light source lamps at once, with a cumulative flash life of about 20 years; Internally equipped with limited thermal constant temperature protection circuit and lightning protection device.
The lampshade of this product is molded from polycarbonate plastic that is resistant to sunlight aging155Millimeter Fresnel principle lens; The lamp base is made of aluminum alloy casting, and the surface is treated with electrostatic spraying technology, which has the advantages of small size, light weight, anti-aging, corrosion resistance, and durability.
Working voltage |
AC:220V （ +40V/-120V ） |
dynamic power |
50W |
Light source |
Pulse strobe xenon lamp tube |
Lamp lifespan |
Single lamp tube>108Number of times |
Light intensity |
Red (medium intensity)>40000cd White (high intensity)>100000cd |
Flash frequency |
Usually: 20-60 times/minute (adjustable) |
Light controlled sensitivity |
0-300LX (automatically turned off during the day and turned on at night) |
Working environment |
-40 ℃～+70 ℃ |
Protection level |
IP65 |
·Chassis installation dimensions |
Chassis with a diameter of 220mm, evenly distributed with 4 to 11 holes on the pitch circle with a diameter of 195mm |
Net weight of lamp |
About 4.0Kg |
Scope of application |
Usually: Red light is used for buildings below 150 meters, and white light is used for buildings above 150 meters |
》》》For free selection/quotation, please contact us: Shaanxi Saide Flow Meter Mobile: Zhang Wei《《《
