HY-6 (A) double-layer speed regulating oscillator

1、 Introduction:

HY-6 (A)Double-layer speed controlled oscillatorIt is an ideal tool for laboratories and laboratories in various colleges and universities, environmental protection, health, epidemic prevention, petroleum, metallurgy, chemical, grain and other units,HY-6 (A) double-layer speed regulating oscillatorGreatly improving the work efficiency of laboratory personnel, it can be used for solution analysis in containers such as test tubes, separatory funnels, and triangular flasks, solving the problem of movement during the operation of other oscillators without noise, and adding a timing device, which is convenient for laboratory personnel.

IIHY-6 (A)Double-layer speed controlled oscillatorTechnical parameters:

1. Oscillation frequency: starting -220 times/minute (stepless speed regulation) A: for speed measurement (speed digital display)
2. Vibration amplitude: 20mm
3. Working method: Spinning
4. Single phase AC power supply: 220V ± 10V 50HZ
5. Timing range: 0-120 minutes
6. Motor power: 100W
7. Working dimensions: (600mm × 500mm) × 2

IIIHY-6 (A)Double-layer speed controlled oscillatorusage method:

When using this instrument, first connect the power supply, then place the volumetric flask that needs to oscillate the solution into the spring fixture, cover the mouth with a rubber stopper, turn on the timer, select the time or position that you need to control, and then turn on the power switch to start working. When working, please choose the oscillation speed that you are satisfied with. The speed control switch is controlled by the timer, and it should start at a low speed when starting up.

4HY-6 (A)Double-layer speed controlled oscillatormatters needing attention:

To ensure safety, please connect the ground wire (i.e. three pin plug) when using
When not working, the power should be turned off and disconnected to prevent accidents.
3. The instrument should be kept clean and dry, and it is strictly prohibited to use a metal hammer to strike it.
