Coal mill oil station oil filter

NegotiableUpdate on 07/16

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The Tongrui brand ZJD oil filter products are widely used in power, oil and gas, mining, machinery manufacturing, steel, metallurgy, chemical, railway, papermaking, pharmaceuticals, aviation, shipbuilding, and various large enterprises.

Product Details

The lubricating oil for the coal mill oil station generally requires more than ten barrels of oil, with each barrel costing around 3000 yuan. When the quality of lubricating oil deteriorates, using a multifunctional vacuum oil filter online for oil filtration can not only improve the quality of the oil and meet the technical requirements for use, but also save a lot of maintenance costs caused by oil changes, ensuring that the coal mill can operate safely and economically without deteriorating the oil quality.

Scope of application:

The ZJD lubricating oil vacuum filter is mainly developed and produced based on the characteristics of high impurity and water content in industrial lubricating oils such as medium and high viscosity lubricating oils and gear oils. The machine has a short processing cycle, high efficiency, and can quickly remove water, gas, impurities, and volatile substances (alcohol, gasoline, ammonia, etc.) from the oil, improve the quality of the oil, restore the viscosity, flash point, and performance of the lubricating oil.

It can quickly remove water, gas, and mechanical impurities from oil, flash evaporate light acids and hydrocarbons, improve oil quality, and restore the performance of lubricating oil. Ensure the normal operation of power, hydraulic, and lubrication systems.

Product Features:

Strong impurity removal ability, large and deep precision filter materials can remove fine particles from oil.

Ø Multi stage drum filter, large flow washable filter element, high filtration efficiency, using step-by-step encryption technology, so that even heavily polluted lubricating oil can be restored to within the "Operating Turbine Oil Pollution Control Standard".

Advanced medium heat absorption and condensation system.

Ø Automatic temperature control heating, automatic separation of condensate device, easy to operate, safe, and reliable.

ØThe super strong vacuum separator set can separate a large amount of water from the oil, as well as remove trace amounts of water from the oil.

Deep level, high-precision FH rectangular filtration system can effectively remove iron filings, dust, and impurities from oil.

The Tongrui technology for independently developed H, P, and M polymer materials.

Using high-quality raw components and connecting sealing materials, it meets the high temperature requirements for filtering high viscosity lubricating oil and expands the types and range of oil that can be purified by the oil filter.

Ø Using high-quality filter materials, with a large capacity for dirt absorption, corrosion resistance, high temperature resistance, good mechanical strength, high impurity removal accuracy, and long service life.

Humanized design, dual infrared liquid level control system, electrical automatic protection control system with phase sequence protection, overload protection, overpressure protection, and temperature constant automatic control system ensure easy operation, safety, and reliability. This machine can work online for a long time, with a unique oil pump, low noise, and meets the world's high environmental standards.

Advantageous Technology:

The processed engine oil and lubricating oil of this machine have low water content and high impurity accuracy, and can be reused repeatedly in high-precision and lubricating equipment at home and abroad.

And the machine has a novel design and is easy to use, which can truly save fuel and reduce consumption for customers.

Indicator Name	unit	ZJD-6	ZJD-10	ZJD-20	ZJD-30	ZJD-50	ZJD-75	ZJD-100	ZJD-150	ZJD-200
internet traffic	L/H	360	600	1200	1800	3000	4500	6000	9000	12000
Working vacuum	Mpa	-0.06 ～ -0.095
Working pressure	Mpa	≤0.4
Constant temperature control range	℃	0 ～ 100
water content	PPm	≤100
cleanliness	NAS	Level 6-8
Filtration	Um	3-10
power supply		380V/50Hz (according to user requirements)
Emulsification value	min	≤15min
work noise	dB（A）	≤75			≤78		≤80		≤82
Electric-heating power	kW	9	15	30	30	45	60	72	90	120
Total electric power	kW	11	17	32	33	48	66	78	98	130
Inlet (outlet) pipe diameter	mm	15	25	25	25	32	42	50	50	60
Equipment weight	Kg	380	450	550	600	750	850	1000	1200	1500

Quality assurance, debugging, and after-sales service requirements

1. The supplier is responsible for guiding the initial installation of the oil filtration equipment. And send relevant personnel to the site to guide installation and operation.

2. After the installation of the oil filtration device equipment, the supplier shall conduct debugging. When both parties confirm that the operating effect meets the specified technical requirements, the final acceptance certificate shall be issued in accordance with the provided technical specifications. The supplier is responsible for providing guidance and training on the operation of the oil filtration device.

3. The supplier shall provide a one-year free warranty commitment for the entire machine in accordance with regulations. In case of any problems, the supplier shall send personnel to the site within three days for handling. And provide the necessary accessories for the oil filtration device at any time.

4. The oil filtration device is randomly equipped with qualified technical materials, including the host manual, main component user manual, operation and maintenance manual, electrical schematic diagram, and spare parts catalog.

If the purchased supporting equipment is updated due to technological progress and old models are eliminated, the supplier is responsible for technical transformation or product upgrading. The supplier guarantees to provide technical guidance free of charge during after-sales service.
