CNC milling machine VMC650 small CNC milling machine professional CNC milling machine manufacturer

VMC650Main features of CNC milling machine:

VMC650 CNC milling machineIn standard configuration, the feed axis isXTheYTheZThree coordinate three linkage control. It can complete various processes such as drilling, milling, boring, expanding, and reaming for complex parts such as disks, plates, shells, cams, and molds in one clamping. Equipped with a fourth axis CNC indexing head or rotary worktable, it can process more complex parts such as spiral grooves on the rotating body.

VMC650 CNC milling machineWhile meeting the above functions, it also has a rigid tapping function. By clamping the workpiece once, multiple cutting tools can be continuously combined for processing, greatly improving the efficiency of the machine tool, ensuring accuracy in multiple processes of part processing, reducing clamping times, reducing auxiliary working hours, and eliminating the trouble of manual tool changing and alignment, achieving automatic modernization processing.

This model of CNC milling machine is suitable for processing various types of parts, especially for processing complex shapes, multiple processing contents, and parts with high precision requirements, which can demonstrate its superiority.

VMC650Main structural characteristics of CNC milling machine:

1VMC650 CNC milling machineThe bed frame casting adopts a high rigidity cast iron structure, and the basic components are molded with resin sand and treated with aging (tempering process), ensuring the accuracy stability of the machine tool for long-term use and providing a guarantee for the reliability of the machine tool performance.

2、VMC650 CNC milling machineXTheYTheZThree directions of feed, using high-precision and high-strength ball screws, all with pre stretched structures, high feed speed, and high positioning accuracy of the machine tool;

3、VMC650 CNC milling machineXTheYTheZStainless steel telescopic covers are used in all three directions for sealed protection, ensuring the cleanliness of the screw and guide rail, and guaranteeing the transmission and motion accuracy of the machine tool;

4、VMC650 CNC milling machineThe external protection is designed with a fully enclosed structure, which is safe, reliable, and aesthetically pleasing;

5、VMC650 CNC milling machineAdopting a centralized automatic intermittent lubrication device, the lubrication is sufficient and reliable, and can lubricate the guide rails, screws, and other lubrication points in three directions at regular and quantitative intervals; When the fuel tank is short of oil, the system will automatically sound an alarm;

6、VMC650 CNC milling machineThe configuration of CNC systems is rich and diverse, with multiple brands of systems available for users to choose from, such as Japan's Fanuc system, Taiwan's new generation system, Kandi system, and other different grades and brands.

7、VMC650 CNC milling machineAll three axes are detected by laser interferometer and compensated for pitch error.

VMC650Main parameters of CNC milling machine:

VMC650 CNC milling machineImportant component configuration table

(1)From the date of final acceptance of the machine tool, Party B shall provide three guarantee services for the product, with a warranty period of12Within the warranty period of one month, free maintenance will be provided for the product.

(2)During the warranty period, if it is confirmed that the mechanical appearance or internal damage is caused by the user's reasons, such as during loading and unloading transportation or prolonged storage time; Any human damage caused by improper operation or self disassembly and modification is not covered by the above free warranty, and the user must pay all repair and refurbishment costs.

(3)If the machine tool malfunctions and the user information is obtained, and the cause of the malfunction and the corresponding measures can be accurately determined, an immediate response will be given. If an immediate response is not possible, it will be provided24Reply within hours and send someone to the site as soon as possible to handle it. The specific time depends on the preparation time of the parts.

(4)After the warranty period has expired, our company will continue to provide repair services to users and charge part costs and service fees according to our company's charging standards.
