ZQ series automatic folding tape sealing machine

NegotiableUpdate on 06/16
Model
Nature of the Manufacturer
Producers
Product Category
Place of Origin

Overview

Using adhesive tape to seal the box, it is economical, fast, and easy to adjust. Mainly suitable for sealing and packaging cardboard boxes, it can be operated independently or used in conjunction with assembly lines. The tension of the sealing tape of the conveyor belt is adjustable and suitable for soft and hard cardboard boxes. The front, side, and back covers of the cardboard box automatically fold in, quickly and smoothly. Using belt drives on both sides, the upper and lower sealing heads are sealed simultaneously or the upper sealing head is sealed, suitable for continuous sealing of cardboard boxes with consistent specifications.

Product Details

ZQ series automatic folding tape sealing machine

ZQ series automatic folding tape sealing machine


Using adhesive tape to seal the box, it is economical, fast, and easy to adjust. Mainly suitable for sealing and packaging cardboard boxes, it can be operated independently or used in conjunction with assembly lines. The tension of the sealing tape of the conveyor belt is adjustable and suitable for soft and hard cardboard boxes. The front, side, and back covers of the cardboard box automatically fold in, quickly and smoothly. Using belt drives on both sides, the upper and lower sealing heads are sealed simultaneously or the upper sealing head is sealed, suitable for continuous sealing of cardboard boxes with consistent specifications.

Power supply voltage (V/Hz)

AC 220/50 110/60

Power (W)

200

Gas source pressure (Mpa)

0.4-0.6

Sealing size (L × W × H) (mm)

MAX600×500×500

Sealing size (L × W × H) (mm)

MIN250×150×180

Sealing speed (cartons/minute/min)

10-20 (for reference only)

Conveyor belt speed (m/min)

20

Tape material

BOPP,PVC, Water free adhesive tape

Workbench height (mm)

600-750

Tape specification (m/m)

48 60 76 (optional)

Dimensions (L × W × H) (mm)

1830 (with bracket 2640) × 920 × (1480~1640)

Net weight (kg)

300
