WTQ-32 Static Torque Sensor

◆ Features and Applications
·Resistance strain is an integrated product composed of sensitive components and integrated circuits
High precision, stable and reliable performance, low to medium range torque measurement, easy installation and use.
·Static torque measurement. One end is connected by an external square key, and the other end is connected by a flange.

TECHNICAL INDEX

Parameters

TECHNICAL INDEX

Range

0～20,50,100,200,300,500Nm

response frequency

100μS

sensitivity

1.5±10% mV / V

insulation resistance

≥5000MΩ/ 100VDC

Zero point output

±1% F.S.

Excitation

10VDC(9-15VDC)

Nonlinear

±0.1，0.3% F.S.

Temperature compensation range

-10 ~ 60℃

lag

≤±0.05% F.S.

Working temperature range

-20 ~ 65℃

repeatability

≤±0.05% F.S

Safe Overload

150% F.S.

creep

≤±0.03% F.S/30min

Extreme overload

200% F.S.

Temperature sensitivity drift

0.03% F.S. / 10℃

Cable size

Ø5.2×3m

Zero temperature drift

0.03% F.S. / 10℃

Electrical connection

Red/E+, Black/E -, Green/S+, White/S-

Input Resistance

350,750±10Ω

material

Stainless steel or alloy steel

Input Resistance

350,700±5Ω

Other requirements

customizable
