Transient absorption spectrometer
NegotiableUpdate on 05/30
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Specification: Model: femtoframeII Quantity: Brand: Packaging: Price: Transient absorption spectrometer studies molecular properties by exciting the molecular system with "pump" pulses, delaying and obtaining system information with detection pulses.
Product Details
| Specifications: | Model: femtoframeII | Quantity: |
| Brand: | Packaging: | Price: |
The transient absorption spectrometer studies molecular properties by exciting the molecular system with "pump" pulses and obtaining system information through delayed detection pulses.
Our transient absorption spectrometer can adapt to a wide range of transient absorption measurements. It has diverse module designs to allow for the selection of "pump" and "probe" pulses and easy switching between transmission and reflection modes of operation. Standalone and Lab ViewTMCompact design, occupying precious desktop space, with good stability and automated operation. Compact pump source, seamless coverage, and wide tuning.
Features&Advantages
1. Detect transient absorption and simulated emission in liquids, solids, and thin films with a resolution of up to 100fs.
2. Fully computer-controlled
3. Obtaining transient spectra with a wide wavelength range (200-1000nm)
4. 4ns time window (- DP option), 8ns (- DDP option)
5. Transient absorption anisotropy measurement
6. Dual beam specification (- U option) provides ultra-high signal-to-noise ratio performance
|
excite |
SHG; THG; Rainbow |
|
Pump spectral range |
230-12,00nm |
|
Detecting light source |
Continuous white light |
|
Detecting spectral range |
300-750nm；240-620nm and 380-1100nm optional |
|
Scan range |
2ns，1fs resolution； （4ns，2fs optional） |
|
Time resolution |
＜1.7 X pump pulsewidth |
|
noise level |
1.3 x 104OD typical |
|
software |
Standalone and Lab ViewTM |
|
size |
|
|
weight |
|
|
|
|
|
input parameter |
|
|
energy |
＞0.3mJ |
|
pulse width |
30—150fs |
|
Beam Diameter |
5-- |
|
polarization |
Linear，horizontal |
|
Repetition rate |
0.3---3kHz |
|
wavelength |
750---850nm |
|
Beam height |
110nm |
