TMA8J turning and milling composite machine tool

Model Introduction

• One machine for full processing, ultra-high cost-effectiveness

• High performance composite processing machine

• Process integration can reduce manual labor

• Reduce the number of machines and shorten the preparation time for processing

• Suitable for producing multiple varieties and small quantities of complex shaped components




  Standard configuration High speed 20000r/minHigh speed tool spindle for efficient machining

Adopting a direct drive B-axis rotating structure, high-speed and high-precision positioning can be achieved

The knife magazine can store 60 knives

■ Powerful cutting spindle

To prevent the spindle unit from being affected by the heating of bearings and built-in motors, temperature management is carried out through cooling oil.

Meanwhile, the thermal symmetric structure Greatly controlled the heat transfer position, achieving long-term high-precision machining.

■Construction of orthogonal slide track

X. The Y and Z axes are constructed with orthogonal slides to ensure high-precision machining of the machine.

■Compact electromechanical oil air integrated structure

Save space structure and improve productivity per unit area.

■High speed and high-precision B-axis (direct drive type)

Standard tool spindle

Tool spindle High speed 20000r/min

The tool spindle is a single spindle structure in which the turning tool and milling cutter enter from the same spindle hole, without tool interference,

Realize powerful cutting. The B-axis adopts a direct drive high-speed and high-precision rotating structure.

By using the B-axis indexing function, it is possible to machine horizontally from the front or on a sloping surface.

By controlling the Y-axis, milling can be performed at eccentric positions.

Adopting a double-sided constrained tool holder, the taper and end face parts are double-sided constrained and installed into the tool spindle hole,

Can perform high-precision and powerful turning machining.

The drive of the tool spindle adopts an 11kw high-power built-in motor, which can perform powerful milling from low speed to high speed.

■Standard high-speed tool changer

The high-speed tool changing device with cam type mechanical structure achieves tool to tool synchronization in 0.8 seconds.

■The tool magazine for changing tools on the front of the machine can store up to 60 cutting tools

The tool magazine is located on the front of the machine, making it easier for operators to replace and monitor the condition of the tools.

■Tool spindle indexing function

The tool spindle is an independent structure with tool indexing every 90 degrees. The same turning tool can perform internal and external machining. Using a multi head turning tool holder with 4 tools can reduce the number of tool holders and shorten tool exchange time.

■Interference prevention function

Prevent interference between the spindle and tool spindle, back shaft and tool spindle.

exterior view
