Stainless steel pipeline horizontal centrifugal pump

NegotiableUpdate on 02/24

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Product Name: Stainless Steel Pipeline Horizontal Centrifugal Pump Model: IHW100-160 Power 15KW Product Category: Chemical Pump Series → Stainless Steel Pipeline Horizontal Centrifugal Pump Caliber Range: DN80-1000 Flow Range: 131-24000m3/h Head Range: 6.5-135m Our Advantages: In stock, special materials can be customized, product performance is stable, service life is more than 5 years Selection Quotation: You only need to provide the flow rate, head, and motor power of the water pump. If not available, we will calculate for you

Product Details

If you have any questions, you can call: 021-57239999 orClick to consult experts for selection and quotation

Stainless steel pipeline horizontal centrifugal pump

1、 Overview of horizontal centrifugal pump:
ISWH horizontal single-stage single suction chemical pump (horizontal centrifugal pump) is a corrosion-resistant chemical pump based on ISW. This series of horizontal centrifugal pumps has excellent performance, high reliability, long service life, reasonable structure, and beautiful appearance, and is at the forefront of the industry.

2、 Application of horizontal centrifugal pump:
ISWH horizontal single-stage single suction chemical pump (horizontal centrifugal pump) is used to transport liquids that do not contain solid particles, are corrosive, and have a viscosity similar to water. The horizontal centrifugal pump is suitable for industries such as petroleum, chemical, metallurgical, power, papermaking, food and pharmaceutical, and synthetic fiber, with a temperature range of -20 ℃ to+105 ℃.

3、 Working conditions of horizontal centrifugal pump:
1. The suction pressure is ≤ 1.6MPa, or the high working pressure of pump system Z is ≤ 1.6MPa, that is, the pump suction inlet pressure+pump head is ≤ 1.6MPa, and the pump static pressure test pressure is 2.5MPa. Please specify the system working pressure when ordering. When the working pressure of the pump system is greater than 1.6MPa, it should be separately stated when ordering, so that the overcurrent and connection parts of the pump can be made of cast steel materials during manufacturing.
2. Environmental temperature<40 ℃, relative humidity<95%.
3. The volume content of solid particles in the conveyed medium shall not exceed 0.1% of the unit volume, and the particle size shall be less than 0.2mm.
Note: If the medium used is with small particles, please indicate it when ordering so that the manufacturer can use wear-resistant mechanical seals.

4、 Characteristics of horizontal centrifugal pump:
Smooth operation: The absolute concentricity of the pump shaft and excellent dynamic and static balance of the impeller ensure smooth operation without any vibration.
Drip proof: Hard alloy seals made of different materials ensure that there is no leakage during the transportation of different media.
Low noise: The water pump supported by two low-noise bearings runs smoothly, with almost no noise except for weak motor noise.
Low failure rate: The structure is simple and reasonable, and the key parts are of world-class quality; Matching, the whole machine's fault free working time is greatly improved.
Easy maintenance: Replacing seals and bearings is simple and convenient.
More land saving: The exit can be arranged in three directions: left, right, and up, which is convenient for pipeline layout and installation, saving space.

5、 Meaning of horizontal centrifugal pump model:
