RF-GEF Fully Automatic Powder Filling Machine

DESCRIPTION:

shouldDouble ended powder fillingMachine by countryDesigned according to GMP standards, this machine can be combined with bottle sorting machines, capping and capping machines, labeling machines, and other equipment to form an assembly line.

Suitable for packaging powdered materials in industries such as food, medicine, and daily necessities.

Such as milk powder, glucose, protein powder, cocoa powder, coffee powder, Rice noodles, solid drinks and other powder and ultra-fine materials.

causePLC、 The touch screen and weighing system form the control core, maximizing the accuracy and stability of the machine's weighing control.

deviceThe contact material is made of 304 stainless steel material, and well-known brands are selected for motors, cylinders, electrical accessories, pneumatic components, etc., which can also be designated by customers.

Can be applied to food, medicine, and corrosive chemical raw materials.

Centralized dust removal, no dust pollution in the workshop, easy cleaning of residual materials, and can be rinsed with water.

1. All stainless steel structure, modular transparent material box, easy to disassemble and wash without tools.
2. High precision stepper motor controlled filling, precise measurement.(Optional servo motor control)
3. Various product parameter adjustment formulas can be stored for future use, with a maximum storage capacity of 10 formulas.
4Replace the spiral accessoryIt can adapt to various materials ranging from ultrafine powder to small particles.
5Touch ScreenPLC controlNo bottle, no filling, no cap.

Technical parameters:

Detail Display
