ISBME series fully electric injection molding machine

NegotiableUpdate on 02/11
Model
Nature of the Manufacturer
Producers
Product Category
Place of Origin
Overview
This machine is a one-step fully electric molding equipment, suitable for thermoplastic plastics such as PET, PC, PP, etc. It is widely used in the manufacturing of pharmaceuticals, health products, cosmetics and other industries
Product Details
1
This machine is a one-step fully electric molding equipment suitable for thermoplastic materials such as PET, PC, and PP, and is widely used in the manufacturing of pharmaceuticals, health products, cosmetics, and other industries. The equipment adopts a four station rotary device, a hot runner system, and a multi-stage injection molding system. It has four stations for injection molding, temperature control, stretch blow molding, and product extraction, all of which are driven by servo motors, significantly reducing energy consumption. It is the preferred equipment for modern green production.

1

Name ISBM 100E ISBM 180E ISBM 350E
Main screw diameter 35mm 40mm 50mm
Maximum injection container 100cm³ 180cm³ 350cm³
Injection molding force 120kN 200kN 400kN
Blow mold clamping force 50kN 100kN 180kN
total power 40kW 70kW 85kW
operating power 10~20%
Blow molding air pressure 3~3.5Mpa
Working air pressure 0.7~0.9Mpa
cooling water pressure 0.25~0.40Mpa
External dimensions 500x115x300cm
Weight (approximately) 3.8t 5.8t 8.2t
