High pressure chromatography system - NGC BioRad Bole

almighty
Multiple molecular purification capabilities, fully compatible from scientific grade small-scale preparation to process development, supporting your various needs for research expansion from now to the future.

user-friendly
Flexible and customizable platform to meet personalized operational needs. The easy-to-use operating software makes the entire job easy and straightforward.

guarantee
From method design to data analysis, all are completed in one software, ensuring complete and reliable data. Wear resistant accessories ensure long-term stable and reliable operation.

NGC Quest 10 and NGC Quest 10 Plus systems

The NGC Quest 10 and NGC Quest 10 Plus systems are designed to use precise gradient solution mixing for high-resolution separation of biomolecules. Both systems offer:

• The automated 10ml/min system pump and high-precision solution mixing function can provide high-resolution separation for all chromatographic applications

• Using fixed or dynamic injection rings to achieve automatic injection

• By utilizing a hybrid module, gradient separation can be achieved under different pH conditions, enabling rapid process development

• Compatible with C-96 automatic sampler, it can achieve precise and repeatable injection regardless of whether it comes with cooling components or not

• Compatible with BioFrac sub collectors to complete the collection of sample components

• The NGC Quest 10 system comes standard with a single wavelength detector, which can accurately measure protein absorption values and solution conductivity values

• The NGC Quest 10 Plus system comes standard with a multi wavelength detector that can detect up to 4 wavelength parameters. It can accurately measure proteins, peptides, nucleic acids, or chromogenic molecules while also detecting the conductivity value in the system

NGC Scout 10 and NGC Scout 10 Plus systems

NGC Scout 10 and NGC Scout 10 Plus are designed specifically for medium throughput purification needs, enabling automated buffer preparation and rapid protein purification process screening.

These two NGC Scout systems not only include all the functions of the corresponding low-end models NGC Quest 10 and NGC Quest 10 Plus systems, but also include the following features

• A set of buffer preparation valves can complete automatic buffer preparation, while also meeting the automatic formation of buffer concentration gradients, achieving rapid protein purification process screening

• A set of pH valves can monitor the changes in pH during the purification process in real time, or monitor the gradient separation under different pH conditions, achieving rapid process method development

• A set of single wavelength detectors (NGC Scout 10 system)

• A set of multi wavelength detectors (NGC Scout 10 Plus system)

NGC Discover 10 and NGC Discover 10 Pro systems

The NGC Discover 10 and NGC Discover 10 Pro systems are designed specifically for high-throughput purification applications, enabling fast and reliable automated operation to meet the needs of process development.

These two configurations not only include the functions of the corresponding NGC Scout 10 and NGC Scout 10 Plus systems, but also include the following features:

• A set of 100ml/min built-in sample pump exclusive injection pump, achieving pollution-free automatic sample injection

• The sample inlet valve can automatically switch between multiple samples or buffer solutions, accelerating the process of method development, column cleaning, and regeneration

• A set of column switching valves can automatically switch between different chromatography columns without changing the system connection

• A set of sample outlet valves is only available in the NGC Discover 10 Pro system, enabling the collection of large volume samples of up to 12 components

Characteristics and advantages of NGC 10ml chromatography system

A flexible and customizable chromatography system that meets your application and workflow requirements:

• The Guided Fluidics selection tool (under application) can be combined with the Module Discovery system to achieve application based "click" system settings through automatic module function recognition

• Tier Rotate ™ Design to achieve optimal configuration of valves and detectors, thereby minimizing the process path

• Compact design suitable for chromatography refrigerators, laboratory workbenches, or freezers

• Point-to-Plumb ™ Using LED indicators to guide users in connecting pipeline connections

• ChromLab ™ The software provides * system control, automation methods, and analysis options
