Flowline EchoPod DL10/DX10 Series Ultrasonic Liquid Level Sensor from the United States

Flowline EchoPod DL10/DX10 Series Ultrasonic Liquid Level Sensor from the United States

(Flulai) FLOW LINE Ultrasonic Liquid Level Sensor Product Features:

Range of 1.25 meters

Ultrasonic liquid level sensor DL10 outputs 4-20mA

Ultrasonic liquid level sensor DX10 outputs 0-5V voltage signal

The probe material is PVDF, which is resistant to acid and alkali corrosion

Narrow beam angle of 0 degrees, supporting static tube technology

WebCal software calibration, protection level IP67

Flowline EchoPod DL10/DX10 Series Ultrasonic Liquid Level Sensor from the United States

Range: 1.25m

Accuracy: 3mm

Resolution: 0.5mm

Beam width: 5cm

Dead zone: 5cm

Supply voltage: DL10:24VDC (loop)

DX10:12-24VDC

Temperature compensation: Full range automatic

Surrounding impedance: 400ohms@24vdc

Signal output: DX10:0-5V, 0-10V,

DL10:4~20mA

Configuration: WebCal PC software, USB2.0

Failure protection: DL10:4 mA, 20 mA, 21 mA, 22mA, or save last data

DX10: Optional full tank, empty tank, or save last data

Process temperature: -35 ℃ to 60 ℃

Pressure: 2 bar

Protection level: NEMA 4X (IP65)

Shell material: PC/ABS FR

Probe material: PVDF

Process connection: 1 "NPT (1" G) thread

Cable length: 1.2 meters

Cable material: PVC

Delay: optional

Category: Ordinary

Certification: CE. RoHS
