Capillary laser welding machine
NegotiableUpdate on 02/13
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Capillary laser welding machine
Product Details
1. Laser parameters
laser power ：300W
laser wavelength ：1064nm Laser output mode:QCWPulse emission
Continuous working hours ： ≥8hour Laser welding frequency ：1-100HZ(Continuously adjustable)
pulse width ： 0.3-2ms(Continuously adjustable) Laser welding depth:0.02-2.5mm(Related to materials)
Welding spot diameter ：0.2mm-3mm Maximum power consumption of the whole machine:4KW
2optical system
a) Composition:Reflective mirror, partial reflective mirror, beam expander, focusing mirror, etc
b) Characteristics: Through optical path oscillation and focusing. Develop usable lasers.
c) The specific technical indicators are as follows: focus150
3Laser indication positioning
a) Composition: Red light
b) Features: Clear indication, high degree、long lifespan
4Workbench system
a) Composition:workwearrotating table
5control system：CNC welding specialized software
Chapter 3: Equipment Composition
Accessory name |
Specification Model |
quantity |
Remarks |
chiller |
8500W |
1 |
Ice Yue |
Welding focal length |
150mm |
1 |
Northern Optics Science |
workwear |
定制 |
1 |
Northern Optics Science |
Customized dedicated chassis |
split-type |
1 |
Northern Optics Science |
Equipment external dimensions |
880mm*1000mm*650mm |
1 |
