BS922 Wireless Gateway

Product Introduction: BS922 is a gateway with complete interfaces produced by Beijing Bichuang Technology. It can work for a long time in unmanned areas in the wilderness, combined with sensors from Beijing Bichuang Technology, and uses the existing wireless network of the GPRS network operator (China Mobile Communications Corporation) to connect the data collected by the sensors to the network and transmit it back to the designated data center; It can also directly utilize existing wired network resources through the LAN port to network the data collected by sensors and transmit it back to the designated data center. It can be said that BS922 is suitable for both remote monitoring in the field and close range big data transmission (through LAN port). It can form a wireless sensor network through wireless radio modules and a distributed testing system through RS485 or CAN ports. Contact us without link information!

The CPU operates at a frequency of up to 454MHz and has strong processing capabilities;
128MB of system memory;
Comes with 1GB of flash memory, leaving 800MB of data storage space;
Industrial grade Linux operating system;
Support remote wireless updates of internal programs;
Support remote access, view logs, and download programs;
Watchdog and power failure protection;
Equipped with an independent RTC clock chip;
Support self diagnosis of faults and upload results;
Compatible with IPV4 and IPV6 (dual stack);
Power supply voltage of 8-24V;
Can adapt to high and low temperature working environments, with a temperature range of -40 ℃ to+70 ℃ and a working humidity of 5-95% RH, and can adapt to various harsh environments;
At the moment of power on, the voltage is 650mA/12V (with built-in power-off protection capacitor for charging). After power on, the average operating current is 160mA/12V with a peak value of 200mA/12V.

Widely used in various industrial control and measurement systems, as well as distributed/distributed power monitoring systems.
